| Image Sensor |
CIS x 2 |
| Optical Resolution |
600 dpi |
|
|
|
|
| Hardware Resolution |
Flatbed: 600 x 1200 dpi |
|
| ADF: 600 x 600 dpi |
|
| Scan Modes |
Color: Input 48-bit, Output 24-bit |
| Grayscale: Input 16-bit, Output 8-bit |
| Black & White: 1-bit |
|
|
|
| ADF Capacity |
50 sheets (A4/ Letter, 70 g/㎡ or 18 Lbs), Max. thickness under 5mm (0.2″). |
|
| Note: Maximum ADF capacity varies, depending upon paper weight. |
|
| Scanning Speed ( ADF ) |
9 ppm/ 10 ipm (Color mode, 200 dpi, A4 Portrait) |
|
| 20 ppm/ 40 ipm (Grayscale mode, 200 dpi, A4 Portrait) |
|
| 20 ppm/ 40 ipm (B&W mode, 200 dpi, A4 Portrait) |
|
| Note: Results may vary depending upon your scanning application, computer processor and system memory. |
|
|
|
|
| Scanning Area (W x L) |
Flatbed: |
| Max. 216 x 297 mm (8.5″ x 11.69″) |
| Min. 12.7 x 12.7 mm (0.5″ x 0.5″) |
| ADF: |
| Max. 216 x 356 mm (8.5″ x 14″) |
| Min. 13.2 x 13.2 mm (0.52″ x 0.52″) |
| Acceptable Paper Sizes (W x L) |
Flatbed: |
|
| Max. 216 x 297 mm (8.5” x 11.69”) |
|
| Min. 12.7 x 12.7 mm (0.5” x 0.5”) |
|
| ADF: |
|
| Max. 220 x 356 mm (8.66” x 14”) |
|
| Min. 90 x 50.8 mm (3.55” x 2”) |
|
|
|
|
| Acceptable Paper Weight (Thickness) |
50 to 120 g/㎡ (14 to 32 Lbs) |
| Daily Duty Scan ( Sheets ) |
1,500 |
|
|
|
|
| Roller Lifetime (Scans) |
100,000 |
| Pad Lifetime (Scans) |
25,000 |
|
|
|
|
| Action Button |
Scan, PDF, Custom |
| Power Supply |
24 Vdc/ 0.75 A |
|
|
|
|
| Interface |
USB 2.0 / RJ45 LAN |
| Net Weight |
3.78 Kgs (8.33 Lbs) |
|
|
|
|
| Dimensions (W x D x H) |
418 x 326 x 101 mm (16.45″ x 12.83″ x 4″) |
| Protocol |
TWAIN Compliant |
|
|
|
|
| OS |
Windows XP / Vista / 7 / 8 / 10 |
|
| LINUX SANE for Systems Integrator. Please contact local sales. |
|
| Hardware Requirements |
Pentium® IV 2.4 GHz processor (Pentium IV 3.0 GHz processor recommended) |
|
| DVD-ROM Drive |
|
| One available USB Port (USB 2.0 recommended) |
|
| 1GB RAM (2 GB or higher recommended) |
|
| 2GB free HDD space (3GB or larger recommended) |
|
|
|
